| l Overall Dimension | |||
| 1 | Length(with bucket on ground) | 8020(mm) | |
| 2 | Width(to outside of wheels) | 2800(mm) | |
| 3 | Bucket width* | 2946(mm) | |
| 4 | Height(To the top of the cab) | 3450(mm) | |
| 5 | Wheel base | 3100(mm) | |
| 6 | Min. ground clearance | 450(mm) | |
| l Technical Specification | |||
| 1 | Rated load | 5000(Kg) | |
| 2 | Operating weight | 16500KG | |
| 3 | Rated bucket capacity | 3.1(m3)，2.2-4.5 (m3) | |
| 4 | Max. dump clearance | 3136(mm) | |
| 5 | Dump reach | 1171(mm) | |
| 6 | Min. turning radius(wheel) | 5970(mm) | |
| l Diesel engine | |||
| 1 | Model | WeiChai | WeiChai |
| WP10G220E343 | WD10G220E23 | ||
| 2 | Type | Electronic fuel injection | Direct injection. |
| 3 | Emission level | Ⅲ | Ⅱ |
| 4 | Rated output | 162KW | 162 (kW) |
| 5 | Displacement | 9.726(L) | |
| 6 | Rated speed | 2000 | 2000(r/min) |
| 7 | Max. Torque | 980(N.M) | 900(N.M)@1400 r/min |
| l Transmission System | |||
| 1 | Model | HANGCHI ZL50D-038 | |
| 2 | Type | 4-elements.single stage | |
| 3 | Gear shift position | 2F、1R | |
| 4 | Speed（F/R） | 11.7/15.9，40.3 | |
| 5 | Max. drawing force | 170kN | |
| 6 | Size of tire | 23.5-25-16PR | |
| l Working Hydraulic System | |||
| 1 | Model of oil pump | JHP3100 | |
| 2 | System pressure | 18MPa | |
| 3 | Model of Muti-way directional valve | GDF32Ⅱ-YL18 | |
| 5 | Pilot valve | ||
| l Steering System | |||
| 1 | Model of steering pump | JHP2080L01 | |
| 2 | Model of redirector | TLF2J-800-22-A | |
| 3 | Model of priority valve | YXL-F250F-N7 | |
| 4 | System pressure | 16MPa | |
| l Brake System | |||
| 1 | Type of traveling brake | Caliper disc brake | |
| 2 | Air pressure | 6-7.5(kgf/cm2) | |
| 3 | Type of parking brake | Clamp brake | |
| l Oil Capacity | |||
| 1 | Fuel(diesel) | 280(L) | |
| 2 | Engine lubricating oil | 24(L) | |
| 3 | Oil for converter and gear box | 45(L) | |
| 4 | Oil for hydraulic system | 240（L) | |
| 5 | Oil for driving axles（F/R | 18/18(L) | |
